FD 05855 P is an unshielded TPE-PUR servo cable for moving machine components, power chains and industrial control circuits. Fine-stranded copper conductors, TPE core insulation and a grey PUR outer sheath support flexible automation-cable routing.
Applications
Use FD 05855 P for measurement, control, regulating and auxiliary-power circuits in machinery, production lines and automation systems. Select the exact core count and cross-section according to current, voltage drop, movement cycle and protective-conductor requirements.
Construction
- Fine-stranded bare copper conductors to EN 60228 Class 6.
- TPE core insulation with black cores and continuous white numbering.
- Green/yellow protective conductor for applicable configurations.
- Non-woven wrapping and a grey RAL 7001 PUR outer sheath.
Technical performance
The cable is rated 300/500 V and tested at 4 kV. Flexible installation is specified from -40°C to +70°C, while fixed installation is specified from -50°C to +70°C. Minimum bending radius: 5 × cable diameter for flexible use and 3 × for fixed installation. The sheath is flame-retardant to EN 60332-1-2, UV-resistant to ASTM G154 and halogen-free.
Request a Quote
Share your core count, cross-section and installation conditions with TEBAOFLEX. Request a Quote.
Servo and motion cable selection
Select this cable only after confirming voltage, EMC requirements, movement duty, temperature and bending radius. Its conductor, screen and sheath are intended for defined machine-cable conditions rather than unrestricted use.
Technical specification
| Parameter | Specification |
|---|---|
| Model | FD 05855 P |
| Rated Voltage | 300/500 V |
| Conductor | Fine-stranded bare copper, EN 60228 Class 6 |
| Core Insulation | TPE |
| Screen | Unshielded |
| Outer Sheath | PUR, grey RAL 7001 |
| Temperature Range | Flexible: -40°C to +70°C; fixed: -50°C to +70°C |
| Standards | Adapted to DIN VDE 0250/0281/0282; EN 60332-1-2 |
Installation guidance
Maintain the stated bending radius and confirm screen termination where electromagnetic compatibility is required. Review the cable route, cycle count and mechanical loading before installation.
Related options
Compare this construction with a related servo cable. Send your requirements for a technical quotation.
