HZLBi high-voltage silicone ignition cable is a heat-resistant single-core ignition cable with tinned copper strands and silicone insulation for high-voltage connection duties.
Applications
HZLBi is suitable for high-temperature ignition circuits where a flexible, halogen-free silicone cable is needed. Its weather resistance and stated low-temperature flexibility support demanding fixed or moving installation conditions within the documented limits.
Construction
Tinned copper strands in silicone EI2 insulation, with a reddish-brown sheath. The construction is halogen-free and designed for high-voltage testing performance.
Technical Parameters
| Parameter | Value |
|---|---|
| Test voltage, 5 mm outer diameter | 15 kV |
| Test voltage, 7 mm outer diameter | 20 kV |
| Temperature range, fixed | -40°C to +180°C |
| Temperature range, flexible | -25°C to +180°C |
| Short-time temperature | +250°C |
| Minimum bending radius | 7.5 × d |
| Halogen-free | IEC 60754-1 |
| Fire performance | IEC 60332-1-2 |
Available Size Options
| Cross section (mm²) | Largest strand (mm) | Outer diameter (mm) | Copper figure (kg/km) | Weight (kg/km) |
|---|---|---|---|---|
| 1.0 | 0.26 | 5.0 | 9.6 | 35 |
| 1.0 | 0.26 | 7.0 | 9.6 | 62 |
Values are nominal. Confirm cable diameter, voltage test requirement and installation condition before ordering.
