ECS-HT VDE 10 kV Silicone Ignition Wire is a single-core, high-temperature ignition cable for electric-arc and burner ignition circuits. It combines a flexible tinned copper conductor with EI2 silicone insulation for demanding thermal environments.
Applications
This ignition wire is specified for ignition circuits and electric-arc generation in piezo-electric components, gas burners, oil burners, boiler equipment and professional appliances.
Construction and Performance
- Flexible Class 5 tin-plated copper conductor supports practical installation.
- EI2 silicone insulation supports continuous operation from -60°C to +180°C.
- The construction is referenced as halogen-free to IEC 60754-1 and EN 60754-1.
- Standard insulation colour options include white, black, brick red and colourless.
Technical Specifications
| Specification | Value |
|---|---|
| Cable type | Single-core silicone insulated ignition wire |
| Conductor | Flexible tin-plated copper, Class 5 to IEC 60228 / DIN VDE 0295 |
| Insulation | Silicone rubber, type EI2 to DIN EN 50363-1 |
| Rated voltage | 1.8/3.0 kV |
| Pulse voltage | 10 kV |
| Operating temperature | -60°C to +180°C |
| Halogen-free reference | IEC 60754-1 / EN 60754-1 |
Available Sizes and Ratings
| Nominal cross-section | Nominal stranding | Max. resistance at 20°C | Insulation thickness | Nominal diameter | Approx. weight |
|---|---|---|---|---|---|
| 0.75 mm² | 24 x 0.20 mm | 26.7 Ω/km | 1.3 mm | 3.8 mm | 22.0 kg/km |
| 1.0 mm² | 32 x 0.20 mm | 20.0 Ω/km | 1.3 mm | 3.9 mm | 24.6 kg/km |
| 1.5 mm² | 30 x 0.25 mm | 13.7 Ω/km | 1.3 mm | 4.2 mm | 30.7 kg/km |
Selection Guidance
Confirm conductor size, pulse-voltage requirement, routing conditions and ambient temperature before specifying the cable. For a confirmed configuration or custom insulation colour, request a quote from TEBAOFLEX CABLE.
