Type P 600/1000V Single Conductor Unarmored Marine Power Cable is a flexible single-core power cable for marine, offshore and industrial electrical systems. The construction pairs a soft-annealed tinned copper conductor with irradiated cross-linked polyolefin insulation for durable low-voltage power distribution.
Marine, Offshore and Industrial Applications
This single-conductor Type P cable is intended for fixed or floating marine facilities, shipboard power systems, land-based installations and oilfield equipment. It is suitable for cabinet and raceway installations when the selected configuration and installation rules are verified for the project.
Construction and Material Performance
- Flexible soft-annealed tinned copper conductors provide reliable termination and flexibility.
- Irradiated cross-linked polyolefin insulation is selected for dielectric performance and resistance to oil, drilling fluids, moisture, abrasion and UV exposure.
- The unarmoured construction supports installations where a compact, single-core power cable is required.
- Final compliance, approvals and ampacity must be confirmed against the selected size and project specification.
Technical Parameters
| Parameter | Value |
|---|---|
| Rated voltage | 600/1000 V AC, phase-to-phase |
| Conductor range | 22 AWG to 1111 kcmil |
| Conductor | Flexible soft-annealed tinned copper |
| Insulation | Irradiated cross-linked polyolefin (XLPO), Type P |
| Maximum insulation operating temperature | 125°C |
| Typical continuous temperature reference | 110°C, subject to the applicable installation standard |
| Design references | 46 CFR Parts 110 & 111; API RP-14F/FZ; IEEE 45.8; IEC 61892-4; IEC 60092-350/353/360 |
| Construction | Single conductor, unarmoured |
Representative Size Data
| Conductor Size | Nominal Area | Overall Diameter | Approx. Weight | Ampacity at 45°C |
|---|---|---|---|---|
| 22 AWG | 0.38 mm² | 2.33 mm | 10 kg/km | 9 A at 100°C |
| 10 AWG | 5.5 mm² | 4.51 mm | 70 kg/km | 58 A at 100°C |
| 4 AWG | 21 mm² | 9.02 mm | 259 kg/km | 128 A at 100°C |
| 1/0 AWG | 56 mm² | 13.36 mm | 607 kg/km | 227 A at 100°C |
| 444 kcmil | 227 mm² | 24.31 mm | 2322 kg/km | 588 A at 100°C |
| 1111 kcmil | 562 mm² | 36.83 mm | 5445 kg/km | 1025 A at 100°C |
Specification Support
Share the operating voltage, conductor size, installation method, ambient temperature and required compliance documentation. TEBAOFLEX can help identify a suitable configuration before quotation.
