CS-ES / ECS-ES extra-flexible silicone wire is a single-core solution for installations that require a small bending radius and repeated flexing at high temperatures. It is available with a Class 6 bare copper or tinned copper conductor.
Key Features
- Class 6 extra-flexible conductor construction in accordance with IEC 60228.
- Silicone insulation supports use from -60 °C to +180 °C.
- Designed for alternate bending and low bending-radius cable routing.
- Available in 300/500 V and 600/1000 V configurations according to conductor section.
Typical Applications
Use this wire in industrial appliances, measuring cable assemblies, equipment with repeated movement, and hot areas where a highly flexible single-core conductor is required.
Technical Parameters
| Parameter | Specification |
|---|---|
| Conductor options | Class 6 bare copper (CS-ES) or tinned copper (ECS-ES) |
| Insulation | Silicone rubber |
| Rated voltage | 300/500 V or 600/1000 V by conductor section |
| Test voltage | 2 kV or 3 kV by conductor section |
| Operating temperature | -60 °C to +180 °C |
| Flexibility | Extra-flexible; suitable for alternate bending |
| Reference standards | IEC 60228; IEC 60754-1/-2; IEC 61034-2; NF C 32-070 C1 |
Selection note: Select the voltage class and conductor section according to the installation design.
Specify Your Requirement
For a configuration review, provide the conductor size, voltage requirement, installation environment, and any required approvals to the TEBAOFLEX technical team.
