Style 3367 / 3135 / 3139 / 3143 200°C silicone wire is a single-core high-temperature wire family for equipment that requires flexible routing and silicone insulation performance up to 200 °C. The styles cover 300 V and 600 V requirements with differing insulation thicknesses.
Key Features
- Continuous operating temperature from -60 °C to +200 °C.
- 300 V option in style 3367 and 600 V options in styles 3135, 3139, and 3143.
- Silicone rubber insulation with stated resistance to thermal shock and UV.
- Bare, tinned, nickel-plated, and silver-plated conductor options listed across the style family.
- Source data identifies UL 758, CSA C22.2 No. 210, horizontal flame test, FT2, and halogen-free references.
Applications
Designed for electrical heating appliances, rotating machines, lighting, and industrial wiring in hot environments.
Technical Parameters
| Parameter | Specification |
|---|---|
| Product styles | 3367 / 3135 / 3139 / 3143 |
| Rated voltage | 300 V or 600 V by style |
| Test voltage | 10 × rated voltage |
| Operating temperature | -60 °C to +200 °C |
| Insulation | Silicone rubber |
| Listed conductor section range | 0.13 to 4 mm² for the named styles |
| Typical insulation thickness | 0.38 mm, 0.76 mm, 1.14 mm, or 1.58 mm by style |
| Standards and tests | UL 758; CSA C22.2 No. 210; IEC 60754-1 / EN 60754-1; FT2 |
Selection Guidance
Specify the style, rated voltage, insulation thickness, conductor finish, and conductor section for a correct quotation.
For a configuration review, provide the required conductor size, voltage class, installation conditions, and applicable approval requirements to the TEBAOFLEX technical team.
